Radial drilling machine 2A576 completely overhauled - ready for sale!
The excellent and stable type 2A576 radial drilling machine can be used for drilling, boring, reaming and threading. The machine has been completely overhauled and restored to full producbon capacity while maintaining the machining accuracy required by FAT.
Basic technical data:
- Drilling diameter: in steel 80 mm / in cast iron 100 mm
- Headstock travel along the arm: 2000 mm
- Max drilling radius: 2500 mm
- Spindle travel: 500 mm
- Spindle: ISO50
- Stepless sefng of spindle feed rates
- Spindle speed range: 2-1600 rpm.
- Column diameter: 500 mm
- Main drive engine power: 7.5 kW
- Dimensions L/W/H: 4180/1280/4125 mm
- Weight: 12 tons
This drilling machine meets the minimum safety and health requirements set out in Direcbve 2009/104/EC, known as the "Tools Direcbve".
